Delegation (Agent-as-Tools)

Agents delegation (also called the agent-as-tools pattern) lets one agent hand off work to other, more specialized agents and aggregate their results. Splitting capability across focused agents keeps prompts smaller and instructions clearer, which generally makes responses faster and more accurate; by contrast, overloading a single agent with too many instructions and responsibilities can increase latency, cost, and the risk of inaccuracy or hallucination.

This example builds a simple multi-agent workflow where a coordinator delegates order creation and delivery to two specialized sub-agents. Internally, we expose each sub-agent as a tool called delegate with a single parameter:

  • task: a clear description of the work for the sub-agent, written without ambiguous pronouns so it can stand alone.
flowchart LR
  Coordinator[Coordinator agent] -->|transfer_to_order| OrderAgent[Order agent]
  Coordinator -->|transfer_to_delivery| DeliveryAgent[Delivery agent]
  OrderAgent -->|order tasks result| Coordinator
  DeliveryAgent -->|delivery tasks result| Coordinator
  Coordinator --> User[Final response]

The flow works like this:

  1. The coordinate agent calls the suitable sub-agent via the transfer_to_{agent} tool. The tool takes the task string and rewrites it into a single UserMessage.
  2. It invokes the target agent’s run method with that message.
  3. The sub-agent executes independently and returns a structured result.
  4. The coordinator receives that result and uses it—along with its own reasoning—to craft a combined response for the overall workflow.

Implementation

Section titled “Implementation”

Agents delegation example

agents-delegation.ts
import { Agent, tool, type AgentItem } from "@hoangvvo/llm-agent";
import { zodTool } from "@hoangvvo/llm-agent/zod";
import { z } from "zod";
import { getModel } from "./get-model.ts";


// Implement the agent delegation pattern, where a main agent delegates tasks
// to sub-agents. The main agent uses the results from the sub-agents'
// execution to make informed decisions and coordinate overall behavior.
function delegate<TContext>(agent: Agent<TContext>, description: string) {
  return tool({
    name: `transfer_to_${agent.name}`,
    description: `Use this tool to transfer the task to ${agent.name}, which can help with:
${description}`,
    parameters: {
      type: "object",
      properties: {
        task: {
          type: "string",
          description:
            "A clear and concise description of the task the agent should achieve." +
            " Replace any possessive pronouns or ambiguous terms with the actual entity names if possible" +
            " so there is enough information for the agent to process without additional context",
        },
      },
      required: ["task"],
      additionalProperties: false,
    },
    async execute(args: { task: string }, context: TContext) {
      console.log(`[-> ${agent.name} agent]:`, args.task);


      const result = await agent.run({
        context,
        input: [
          {
            type: "message",
            role: "user",
            content: [{ type: "text", text: args.task }],
          },
        ],
      });


      return {
        content: result.content,
        is_error: false,
      };
    },
  });
}


const model = getModel("openai", "gpt-4o");


interface Order {
  customer_name: string;
  address: string;
  quantity: number;
  completionTime: Date;
}


class MyContext {
  readonly #orders: Order[];
  constructor() {
    this.#orders = [];
  }


  addOrder(order: Order) {
    this.#orders.push(order);
  }


  getOrders() {
    return this.#orders;
  }


  pruneOrders() {
    const now = new Date();
    // remove completed orders
    this.#orders.splice(
      0,
      this.#orders.length,
      ...this.#orders.filter(({ completionTime }) => completionTime > now),
    );
  }
}


// Order processing agent
const orderAgent = new Agent<MyContext>({
  name: "order",
  model,
  instructions: [
    "You are an order processing agent. Your job is to handle customer orders efficiently and accurately.",
  ],
  tools: [
    zodTool({
      name: "create_order",
      description: "Create a new customer order",
      parameters: z.object({
        customer_name: z.string(),
        address: z.string(),
        quantity: z.number(),
      }),
      execute(args, context) {
        console.log(
          `[delivery.create_order] Creating order for ${args.customer_name} with quantity ${String(args.quantity)}`,
        );


        context.addOrder({
          ...args,
          // Randomly finish between 1 to 10 seconds
          completionTime: new Date(
            Date.now() + Math.floor(Math.random() * 10000) + 1000,
          ),
        });


        return Promise.resolve({
          content: [
            { type: "text", text: JSON.stringify({ status: "creating" }) },
          ],
          is_error: false,
        });
      },
    }),
    zodTool({
      name: "get_orders",
      description:
        "Retrieve the list of customer orders and their status (completed or pending)",
      parameters: z.object({}),
      execute(_args, context) {
        const now = new Date();


        const orders = context.getOrders();


        const result = orders.map(
          ({ customer_name, quantity, address, completionTime }) =>
            ({
              customer_name,
              quantity,
              address,
              status: completionTime <= now ? "completed" : "pending",
            }) as const,
        );


        const completedCount = result.filter(
          (order) => order.status === "completed",
        ).length;


        console.log(
          `[delivery.get_orders] Retrieving orders. Found ${String(completedCount)} completed orders.`,
        );


        // remove completed orders
        context.pruneOrders();


        return Promise.resolve({
          content: [{ type: "text", text: JSON.stringify(result) }],
          is_error: false,
        });
      },
    }),
  ],
});


// Delivery agent
const deliveryAgent = new Agent({
  name: "delivery",
  model,
  instructions: [
    `You are a delivery agent. Your job is to ensure timely and accurate delivery of customer orders.`,
  ],
  tools: [
    zodTool({
      name: "deliver_order",
      description: "Deliver a customer order",
      parameters: z.object({
        customer_name: z.string(),
        address: z.string(),
      }),
      execute(args) {
        console.log(
          `[delivery.deliver_order] Delivering order for ${args.customer_name} to ${args.address}`,
        );


        return Promise.resolve({
          content: [
            { type: "text", text: JSON.stringify({ status: "delivering" }) },
          ],
          is_error: false,
        });
      },
    }),
  ],
});


// Coordinator agent
const coordinator = new Agent({
  name: "coordinator",
  model,
  instructions: [
    `You are a coordinator agent. Your job is to delegate tasks to the appropriate sub-agents (order processing and delivery) and ensure smooth operation.
You should also poll the order status in every turn to send them for delivery once they are ready.
`,
    `Respond by letting me know what you did and what is the result from the sub-agents.`,
    `For the purpose of demo:
- you can think of random customer name and address. To be fun, use those from fictions and literatures.
- every time you are called (NEXT), you should randomly create 0 to 1 order.`,
  ],
  tools: [
    delegate(orderAgent, "handling customer orders and get order statuses"),
    delegate(deliveryAgent, "delivering processed orders"),
  ],
});


const items: AgentItem[] = [];


const myContext = new MyContext();


for (;;) {
  console.log("\n--- New iteration ---");


  items.push({
    type: "message",
    role: "user",
    content: [{ type: "text", text: "Next" }],
  });


  const response = await coordinator.run({
    input: items,
    context: myContext,
  });


  console.dir(response.content, { depth: null });


  // Append items with the output items
  items.push(...response.output);


  await new Promise((resolve) => setTimeout(resolve, 5000));
}
