Structured output

Agents can combine tools to generate a structured output. Structured outputs are especially helpful when downstream systems expect typed data instead of free-form prose. Common production use cases include:

  • Ticket routing: Map user intents into { category, severity, owner } so incidents flow to the right queue automatically.
  • Data extraction: Pull { company_name, amount, invoice_date } from support chats and push to billing systems.
  • Workflow kicks-offs: Produce { action, arguments } payloads that can be directly executed by automation platforms (for example, Zapier or internal job runners).

The structured output will come as a TextPart and require parsing into an object.

structured-output

Example

Section titled “Example”

In the example below a “travel agent” orchestrates two tools—search_flights and search_hotels—and requires the language model to emit the final answer as JSON conforming to a travel_plan schema. The agent gathers flight and hotel options, merges them into the structured payload, and prints the parsed object so downstream systems can consume it without extra parsing heuristics.

structured-output.ts
import { Agent, getResponseText, tool } from "@hoangvvo/llm-agent";
import type { ResponseFormatOption } from "@hoangvvo/llm-sdk";
import { getModel } from "./get-model.ts";


// Define the model to use for the Agent
const model = getModel("openai", "gpt-4o");


const searchFlightsTool = tool({
  name: "search_flights",
  description: "Search for flights between two cities",
  parameters: {
    type: "object",
    properties: {
      from: { type: "string", description: "Origin city/airport" },
      to: { type: "string", description: "Destination city/airport" },
      date: { type: "string", description: "Departure date in YYYY-MM-DD" },
    },
    required: ["from", "to", "date"],
    additionalProperties: false,
  },
  execute(args: { from: string; to: string; date: string }) {
    const { from, to, date } = args;
    console.log(`Searching flights from ${from} to ${to} on ${date}`);
    return {
      content: [
        {
          type: "text",
          text: JSON.stringify([
            {
              airline: "Vietnam Airlines",
              departure: `${date}T10:00:00`,
              arrival: `${date}T12:00:00`,
              price: 150,
            },
            {
              airline: "Southwest Airlines",
              departure: `${date}T11:00:00`,
              arrival: `${date}T13:00:00`,
              price: 120,
            },
          ]),
        },
      ],
      is_error: false,
    };
  },
});


const searchHotelsTool = tool({
  name: "search_hotels",
  description: "Search for hotels in a city",
  parameters: {
    type: "object",
    properties: {
      city: { type: "string" },
      checkin: {
        type: "string",
        description: "Check-in date in YYYY-MM-DD",
      },
      nights: { type: "number", description: "Number of nights" },
    },
    required: ["city", "checkin", "nights"],
    additionalProperties: false,
  },
  execute(args: { city: string; checkin: string; nights: number }) {
    const { city, checkin, nights } = args;
    console.log(
      `Searching hotels in ${city} from ${checkin} for ${String(nights)} nights`,
    );
    return {
      content: [
        {
          type: "text",
          text: JSON.stringify([
            {
              name: "The Plaza",
              location: city,
              pricePerNight: 150,
              rating: 4.8,
            },
            {
              name: "Hotel Ritz",
              location: city,
              pricePerNight: 200,
              rating: 4.6,
            },
          ]),
        },
      ],
      is_error: false,
    };
  },
});


// Define the response format
const responseFormat: ResponseFormatOption = {
  type: "json",
  name: "travel_plan",
  description:
    "A structured travel plan including flights, hotels, and weather forecast.",
  schema: {
    type: "object",
    properties: {
      destination: { type: "string" },
      flights: {
        type: "array",
        items: {
          type: "object",
          properties: {
            airline: { type: "string" },
            departure: { type: "string" },
            arrival: { type: "string" },
            price: { type: "number" },
          },
          required: ["airline", "departure", "arrival", "price"],
          additionalProperties: false,
        },
      },
      hotels: {
        type: "array",
        items: {
          type: "object",
          properties: {
            name: { type: "string" },
            location: { type: "string" },
            pricePerNight: { type: "number" },
            rating: { type: "number" },
          },
          required: ["name", "location", "pricePerNight", "rating"],
          additionalProperties: false,
        },
      },
    },
    required: ["destination", "flights", "hotels"],
    additionalProperties: false,
  },
};


const travelAgent = new Agent({
  name: "Bob",
  instructions: [
    "You are Bob, a travel agent that helps users plan their trips.",
    () => `The current time is ${new Date().toISOString()}`,
  ],
  model,
  response_format: responseFormat,
  tools: [searchFlightsTool, searchHotelsTool],
});


const prompt = "Plan a trip from Paris to Tokyo next week";


const response = await travelAgent.run({
  input: [
    {
      type: "message",
      role: "user",
      content: [{ type: "text", text: prompt }],
    },
  ],
  context: {},
});


console.dir(JSON.parse(getResponseText(response)));
